Diptrace 3D Component Library

[bitfogav]

Hi all, here is where I am going to be sharing my Diptrace 3D component Library (WRL 2.0 format). I'm sure I'll be updating it quite frequently and adding new components.. (keep checking by for updates)..
To find out how to import the files into Diptrace check out my 3D component tutorial here.

Arduino Stackable Headers (v1.0) - Contains 6,8,10pin

Arduino Stackable Headers.jpg (14.48 KiB) Viewed 19817 times

Arduino Stackable headers v1_0.zip

(25.4 KiB) Downloaded 1529 times

Bi-Color Led Matrix 8x8 (v1.0) - 24pin Led Matrix Display


Matrix_8x8 _led_3mm v1_0.zip

(944.21 KiB) Downloaded 1562 times

Female Headers (v1.0) - Contains Female Headers (Straight/Angled) from 2 to 20 pin configurations.

Female Headers.jpg (16.11 KiB) Viewed 19817 times

Female Headers (v1_0).zip

(363.34 KiB) Downloaded 1483 times

DC Power Jack 2.1mm (v1.0)


DC_PowerJack_2_1mm_v1_0.zip

(71.14 KiB) Downloaded 1467 times

Pin Headers (v1.0) - Contains single/double/straight/angled pin headers (various lengths)

Pin Headers.jpg (29 KiB) Viewed 19813 times

Pin Headers v1_0.zip

(320.43 KiB) Downloaded 1474 times

Leds SMD (v1.1) - Contains 0402,0603,0805,1206

leds smd v1.1.jpg (40.62 KiB) Viewed 19801 times

Led SMD_v1.1.zip

(790.71 KiB) Downloaded 1608 times

USB Mini B (v1.0)


USB_mini_B_v1_0.zip

(157.08 KiB) Downloaded 1462 times

[brad]

Thanks Gav!

Those 0402 LED's I can use straight away with my current project

[brad]

And here they are, thanks again!
